High frequency high-voltage generator

Max power output

55 kW

Inverter frequency

60kHz

Tube Voltage

40~140kV

Tube Current

10mA~500mA

Exposure Time

0.001s~12.5s

mAs

0.1～630mAs

Power Supply

380VAC  Three-phase Power

X-ray Tube Assembly

Dual-Focus

0.6/1.2

Focus Power Output

33kW/78kW

Thermal Capacity

260kJ

Anode Target Angle

12°

Rotary Anode Speed

8500-10800rpm

Tube Thermal Capacity

1000kJ

Radiography Table

Length of the table surface

2000mm

Width of the table surface

760mm

Height of the table surface

≤700mm

Table Longitudinal Moving Range

≥900mm

Table Horizontal Moving Range

≥220mm

Grid Specifications

Grid Density:103L/INCH

Grid Ratio: 10:1

Convergence Distance:120cm

Stationary Type:15〞×18〞

Film Size of the Cassette

Max: 356mm×432mm（14″×17″）

Longitudinal Moving Range of Cassette Hanger

≥560mm

Mechanical movement of the column and cross arm

SID moving distance

450～1200mm

Longitudinal moving range of X-ray tube along the table

≥1370mm

The rotation angle of the X-ray tube around the cross arm axis

≥±180

The rotation range of the X-ray tube around its axis

≥35º

The rotation angle of the X-ray tube around the column axis

4×90°
