Type(Shelves/ Drawer)/Marterial

Shelves/Steel wire with plastic dip coating

Cooling type(Forced air cooling/direct cooling)

Fan cooling

Defrost( automatic/manual)

Automatic

Technical Parameters

Refrigerant

R134a

Power comsuption(kWh/24h)

1.95

Noise level(db)

49.6dB(A)

Ambient temperature（℃）

10~32℃

Temperature range

4±1℃

Control

Compressor brand/Qty

EMBRACO/1

Evaporator type

Radiator-fan

Evaporator marterial

Brass aluminum fins

Condenser type

Tube type

Condenser material

Bondi tube

Sensor type

NTC

Temperature controller

Electronic temperature controller

Display

Digital

Electrical data

Voltage/Frequency（V/Hz)

220/50Hz

Power(W)

160

Electricity (A)

0.6

Compressor

/

Material

Internal material

Stainless steel plate

External material

Sprayed steel plate

Insulation

PU foam

Dimensions

Capacity（L）

108

450ml blood bags

66

Net/Gross weight (KG)

50/55

Overall size（W*D*H  mm)

522×600×1050

Inner size（W*D*H  mm)

432×462×478

Packing size（W*D*H  mm)

572×685×1070

Alarm

High/low temperature

√

Power off

√

Abnormal voltage

/

Temperature controller malfunction

√

Backup battery malfunction

√

Condenser malfunction

No

Ambient temperature

10~32℃

Door ajar

√
