Type(Shelves/ Drawer)/Marterial

Shelves/Steel wire with plastic dip coating

Cooling type(Forced air cooling/direct cooling)

Fan cooling

Defrost( automatic/manual)

Automatic

Technical Parameters

Refrigerant

R134a

 Power comsuption(kWh/24h)

6.31

Noise level(db)

51.2 dB(A)

Ambient temperature（℃）

10~32℃

Temperature range

4±1℃

Control

Compressor brand/Qty

Secop/1

Evaporator type

Radiator-fan

Evaporator marterial

Brass aluminum fins

Condenser type

Radiator-fan

Condenser material

Copper tube fins

Sensor type

NTC

Temperature controller

Electronic temperature controller

Display

Digital

Electrical data

Voltage/Frequency（V/Hz)

220/50Hz

Power(W)

364

Electricity (A)

2.42

Compressor

/

Material

Internal material

Stainless steel plate

External material

Sprayed steel plate

Insulation

PU foam

Dimensions

Capacity（L）

658

450ml blood bags

360

Net/Gross weight (KG)

165/195

Overall size（W*D*H  mm)

1220×648×1885

Inner size（W*D*H  mm)

1100×454×1325

Packing size（W*D*H  mm)

1300×730×2080

Alarm

High/low temperature

√

Power off

√

Abnormal voltage

/

Temperature controller malfunction

√

Backup battery malfunction

√

Condenser malfunction

No

Ambient temperature

10~32℃

Door ajar

√
