Technical data

Type(Shelves/ Drawer)/Marterial

Shelves/ Drawer

Cooling type(Forced air cooling/direct cooling)

Forced air cooling

Defrost( automatic/manual)

Automatic

Refrigerant

R134a

Power comsuption(kWh/24h)

1.91

Noise level(db)

50

Ambient temperature（℃）

10~32℃

Temperature range（℃）

2~8℃

Control

Compressor brand/Qty

EMBRACO/1

Evaporator type

Fin type

Evaporator marterial

Brass aluminum fins

Condenser type

Tube type

Condenser material

Bondi tube

Sensor type

NTC

Temperature controller

Electronic temperature controller

Display

Digital

Electrical data

Voltage/Frequency(V/Hz)

220/50Hz

Power(W)

220w

Electricity (A)

1.15

Material

Internal material

Sprayed steel plate

External material

Sprayed steel plate

Insulation

PU foam

Dimensions

Capacity(L)

306

Net/Gross weight (KG)

95/110

Overall size

640×580×1920

Inner size

540×425×1380

m)                 Packing size

735×651×2100

Alarm

High/low temperature

√

Power off

√

Abnormal voltage

√

Temperature controller malfunction

√

Backup battery malfunction

√

Condenser malfunction

√

Ambient temperature

√

Door ajar

√

Accessaries

Caster

√

Foot

√

Outer door

1/glass/LOW-E

Outer door locker

1

Test hole

Optional

Light(LED/CFL)

LED

USB connector

√

Remote alarm

√

Temperature recorder

Optional

RS232/485connector

/

CO2 backup system

/

LN2 backup system

/
